BECKER-Antriebe GmbH Rolladen Becker Rolladenmotor R8-17-E01 8Nm

Becker roller shutter motor R8-17-E01 8Nm

Hersteller: BECKER-Antriebe GmbH

FG Artikel Nummer: 300201

138,95€

Taxes included. Shipping calculated at checkout.

Express Versand möglich

Abholung bei Fenstergigant möglich

Becker Roller Shutter Motor R8-17-E01

2010 120 139 0

Roller shutter motor without radio control
with blockage and obstacle detection
automatic limit switch detection
VDE certification
Quiet, smooth operation
Automatic curtain length compensation
Can be wired in parallel without a separating relay
pluggable connection cable
Overload protection
This tubular motor is exclusively suitable for use in roller shutters and roller garage doors
To ensure a long service life, only rust-free, weather and moisture-resistant materials are used
Low stress on the curtain and stop due to continuous optimization of the stopping forces
Thanks to an integrated isolation relay, several motors can be connected in parallel and operated via a control unit or switch. The number of connectable motors depends on the load capacity of the interface and the fuse.
The connection cable is connected to the motor via a plug connector, is replaceable, and available in various designs and lengths
In case of high heat development (e.g., due to continuous operation), a thermal circuit breaker interrupts the power supply to the motor. Operation is possible again after cooling down
The curtain can wrap over the motor head. Use is possible even in the tightest spaces
Former/Alternative type designations for this motor: R../17PR+, R../17C PR+, R../17C PRO+ (e.g., R8/17C PR+)
Rated torque: 8Nm
Rated speed: 17 U/Min.
Rated voltage: 230 V
Frequency: 50Hz
Power consumption: 100W
Current consumption: 0.45A
Outer diameter: 45mm
Limit switch range (max. number of revolutions): 64
Protection class IP44
Frequency 50Hz
Total length: 595mm
