Becker roller shutter motor P5-16-E03 5Nm


Price:
Sale price149,95€

Tax included plus Shipping Costs
Delivery time 1-3 Working Days DEUTSCHLAND AUSTRIA BENELUX

Stock:
In Stock - available immediately

Description

Becker Drives Logo

Becker roller shutter motor P5-16-E03 5Nm

2009 120 104 0

High-quality electronic tubular motors for roller shutters and awnings from the German brand manufacturer Becker. For over 100 years, they have been producing high-quality products "Made in Germany." Every drive unit is tested on a standardized test bench for performance, insulation resistance, braking force, and limit switch accuracy. Combined with modern manufacturing in Germany, this ensures the highest quality.

  • Tubular motor with electronic limit switch
  • Suitable for right- and left-hand installation
  • Motor protected against overheating
  • Dynamic torque adjustment to changes in the roller shutter element
  • Soft stop at the top
  • Can be switched in parallel without an isolating relay
  • Motor head can be wound over
  • Easy programming of end positions with and without fixed stops
  • End position setting via conventional control element
  • End Position Status Indicator (ESI) signals missing end positions
  • Automatic increase in contact force for anti-lift devices
  • Top frost protection with automatic curtain length compensation can be additionally activated.
  • Blockage detection in the UP direction (freeze protection)
  • Rated torque: 5 Nm
  • Rated speed: 16 rpm.
  • Nominal voltage: 230 V
  • Power consumption: 85W
  • Current consumption: 0.35A
  • Outer diameter: 35mm
  • Protection class IP44
  • Frequency 50Hz
  • Total length: 434 mm

    Scope of delivery: 1 motor with connection cable

    Certified Becker online retailer

    Payment & Security

    American Express Apple Pay Bancontact BLIK EPS Google Pay iDEAL Klarna Maestro Mastercard MobilePay PayPal Twint Union Pay USDC Visa

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    GPSR Informationen

    General Information

    CE Marking: Yes

    Declaration of Conformity: View Document

    User Manual: View Document

    Manufacturer Information

    Name: Becker-Antriebe Deutschland

    Address: Friedrich-Ebert-Straße 2-4, 35764 Sinn, Germany

    Email: info@becker-antriebe.com

    Website: https://becker-antriebe.com

    European Manufacturer: Yes
